              Feed Pellet Mill Machine SZLH508

              Model
              SZLH508
              Capacity
              4-18t/h
              Main motor power
              160kw
              Conditioner power
              7.5kw
              Speed?of?feeding?screw
              12-120rpm
              Pellet?specification
              φ2,φ3,φ4,φ4.5,φ5,φ6,φ8,φ10mm
              Share With :
              Description
              Features
              Parameters
              Inquiry

              Description

              High Performance SZLH508 Feed Mill Equipment (Feed Pellet Press)
              SZLH series feed pellet machine (pellet press) is an America CPM Model machine with, High-strength precision gear drive,  and Transmission efficiency can be as high as 99%, The normal belt transmission efficiency of 90% -95%, and easy to slip loose, life is short when the belt becomes loose, transmission efficiency will drop a lot, in normal with the same power, gear drive Pellet machine output should be increased by 20% -30% than the belt drive, can work alone with its electric cabinet.It can be used in all kinds of large, middle, and small farms (feed pellet production line) to make feed pellets to feed animals,  raw materials,  can be grain, such as wheat, corn, maize, etc., and some grass, straw also can be applied to this machine, has a very broad application.
              Efficient
              Stable
              low noise
              High Yield
              Low consumption
              Mature Technology
              The Ring Die Feed Pellet Mill Detailed Instructions

              For the machine, raw material can be corn, wheat, and other grains, grass also ok.
              If the raw material is powder, can be made into pellets directly.
              If the raw material is particle size, first, we need to crush them to powder less than 3mm powders.
              there are also some requests for the raw material moisture, it is better if less than 30%.
              If you want to make different size pellets, the size, generally we mean the diameter of the pellets, you can buy several different size ring die.
              The machine can make pellets for poultry, cow, cattle, pig,  chickens, and so on.

              Application: for making cattle, geese, pig, duck, chicken, sheep, rabbit, and other animals, livestock and poultry feed.Such as 2-4mm diameter chick feed pellets and pig feed pellets.2-5mm rabbit feed pellets, 4-8mm cattle or sheep feed pellets. The last pellet length can be adjusted.
              A

              After installation and adjustment,we will train our customers work how to operate;
              B

              Training worker how to maintain and protect
              C

              According to features, we will make complete maintenance rules for you, containing how to maintain, when to maintain,  and who maintains)
              D

              Our company after-sale department will call you at regular intervals, ask if maintain and give advice.

              Features

              Feed Pellet Mill Firm Structure SZLH508 feed pellet machinery

              1

              Machine model: America CPM
              2

              Electric motor: Germany SIEMENS
              3

              Pellet machine bearing: Switzerland SKF
              4

              Full 304 stainless steel conditioner, ensure the high quality of pellet feed.
              5

              We can customize double or three-layer conditionerss for clients.


              Super quality of Henan Strongwin Feed Pellet Mill



              Material thickness of main equipment is more than feed machinery standard 2mm;
              The weight is heavier than feed machinery by 20%.
              Output higher 20%;
              The feed rate of return increases by 3-5%.

              Parameters

              Model SZLH508
              Main motor power 160kw
              Conditioner power 5.5kw
              Feeder power 1.5kw
              Ring die diameter 508mm
              Capacity 4-18t/h
              Finished pellet size φ3,φ4,φ4.5,φ5,φ6,φ8,φ10mm
              Price



              Contact Strongwin to Get Details and Latest Price
